DS650E SERVICE MANUAL
23
UNIT key
000 - No
001 - For kg and lb conversion
010 - For kg, decimal lb and kati conversion
(for HK)
011 ~ 111 - Not used
IR mode protected by
SPAN SW
0 - NO
1 - YES
24
Accumulation
0 - Allow
1 - Inhibit
Accumulation number
display
0 - Allow
1 - Inhibit
Accumulation
display style
0 - Standard (“total”)
1 - Japan (“Add”)
WT data
s
y
nchronization (+ ke
y
only)
0 - Allow
1 - Inhibit
25
Exit from
accumulation mode
after 15 sec time out
0 - Allow
1 - Inhibit
Exit from
accumulation mode
when weight change
0 - Allow
1 - Inhibit
Price accumulation
without removin
g
weight
0 - Allow
1 - Inhibit
Price accumulation
without change weight
(for >=
±
10e)
0 - Allow
1 - Inhibit
26
Decimal point position on price display in
secondary currency
00 - No decimal point for Unit & Total Price
01 - 2nd digit (0000.0) for Unit,
2nd digit (00000.0) for Total Price
10 - 3rd digit (000.00) for Unit,
3rd digit (0000.00) for Total Price
11 - 4th digit (00.000) for Unit,
4th digit (000.000) for Total Price
Rounding for currency conversion
00 - Rounding
01 - Truncation
10 - Cut up
11 - Not used
SPEC NO. BIT 3 BIT 2 BIT 1 BIT 0
27
Exit from secondary
currency mode when
weight change (for >
±
2e)
0 - Allow
1 - Inhibit
Currency symbol for
secondary currency
0 - No symbol
1 - ‘EURO’
Indicator for
secondary currency
0 - Allow
1 - Inhibit
Inverse currency
conversion function
0 - Allow
1 - Inhibit
28
Non-weighing item
accumulation
0 - Allow
1 - Inhibit
Weight range of
Non-weigh item
0 - Always
1 - Net 0d
Weight stability condition
00 - Loose
01 - Normal
10 - Tight
11 - Stringent
