DS650E SERVICE MANAL
1.2. SPECIFICATION
1.2.1. Model Name : DS-650E (DS-6500)
1.2.2. Display Resolution : 1 / 3000, 1/6000, 1/7500
1.2.3. Internal Resolution : 1 / 90000
1.2.4. Capacity : 3kg, 6kg, 15kg, 30kg, 6lb, 15lb, 30lb and 60lb.
1.2.5. Display : 16 DIGITAL 0.56” LED
WEIGHT : 5 digits
UNIT PRICE : 5 digits
TOTAL PRICE : 6 digits
1.2.6. Load Cell : K-type( WD ) load cell
1.2.7. Mechanical Detail : New Display Panel
: New Metal Bracket for Display & Transformer
: New Membrane Keypad
1.2.8. Physical Dimensions : 345 x 428 x 420 mm
Platter Size ( Flat Pan ) : Platter Size 340 × 280mm
1.2.9. Calibration Method : Software Calibration
1.2.10. Power Source : AC 220 V(+10 % ~ -15 % ) 117/100 V
DC 6V 5Ah rechargeable battery (optional)
50Hz/60Hz
1.2.11. Operating Temperature : -10℃ ~ 40℃ ( OIML )
1.2.12. Humidity : 15~ 85 % RH
1.2.13. 18W when using AC power.
3W when using rechargeable battery.
1.3. DETAIL HARDWARE SPECIFICATION
1.3.1. Microcomputer: Hitachi HD6473644(8 Bit, 32K PROM)/HD6433644(8 Bit, 32K
ROM)/HD6433643(8 Bit, 24K ROM)/HD6433642(8 Bit, 16K ROM) .
