OPERATION GUIDELINES
Auxiliary Let Down
(Optional)
Push and hold to engage auxiliary lowering system.
Used when vehicle engine is not operable.
Do no use to operate Digger Derrick continuously.
Foot Throttle Depress with foot to increase engine RPM.
Release to decrease engine RPM.
Tachometer
(Optional)
Used to monitor the engine RPM.
Horn Press to sound horn. Button will be located in lower control
area, depending on configuration.
