DIGGER DERRICK
1-28
463280 - 9/14 Terex South Dakota, Inc. Digger Derrick
OPERATION GUIDELINES
INSTALLED OPTIONS
LOWER RIGHT SECTION OF LOAD CHART
This section of the load chart gives the options that are installed at the time of test to determine the capacity.
If additional options have been added on unit modified, then the capacity is affected. The added weight must
be deducted from the capacity shown on the load chart.
CODE OPTIONS AVAILABLE
FBG Hyd 3rd Fiberglass Hydraulic 3rd Section
FBG Man 3rd Fiberglass Manual 3rd Section
Stl. 3rd Steel 3rd Section
CTI Top Control Selector
ATP Auxiliary Tools
TPP Tilt Pole Plummer
Trans. TPP Transferrable Tilt Pole Plummer
TPP on 2nd Tilt Pole Plummer on 2nd Section
TPP on 3rd Tilt Pole Plummer on 3rd Section
MK IV Mark IV Digger Drive
ESK Eskridge Digger Drive
Aug. Auger
CO
NTR
O
L
S
.
FORM #3405F 7/02
REF: E04G-1196
OPTIONS: FBG HYD 3RD, ESK,
AUG 20, TRANS TPP
To Next Page
