DIGGER DERRICK
1-16
463280 - 9/14 Terex South Dakota, Inc. Digger Derrick
OPERATION GUIDELINES
DIGGER DERRICK CHECKS
ITEM DESCRIPTION ITEM DESCRIPTION
1. Hydraulic Pump 12. Transferable Pole Guide Mechanism
2. Auger Storage Bracket and Mechanism 13. Platform
3. Auger Roll Up Cable 14. Harness
4. Auger to Hex Shaft Retention Bolt 15. Non-Skid and Platform Step
5. Digger to Hex Shaft Coupling 16. Platform Mounting
6. Digger Mounting and Transfer Mechanism 17. Platform Brake
7. Rotation Gear Box 18. Lubrication (see Lubrication Chart)
8. Winch Gear Box 19. Pole Puller
9. Rotation Bearing Bolts 20. Jibs and Attachments
10. Rotation Bearing 21. Digger
11. Pole Guide
6
11
12
21
5
4
2,3
8
7
9,10
18
1
20
19
17
13
15
14
16
