WIRE ROPE
Wire Rope:
Rope: Non-rotating Compak
2070 MPa.
Ø14 mm
35W x 7
Minimum Breaking Force:
165 kN
Rope Length:
110 m
TYRE SPECIFICATIONS
Condition
Speed
Rated Capacity (Min)
Pick & Carry
<1.44 km/h
10500 kg per tyre (dual fitment)
Highway
80 km/h
3000 kg per tyre (dual fitment)
TYRE INFLATION CHART
Position
Construction
Inflation Pressure
Pick & Carry
Highway Travel
Front
14.00 x 20
830 kPa
(120 psi)
620 – 830 kPa
(90 – 120 psi)
Rear
14.00 x 20
620 kPa
(90 psi)
620 kPa
(90 psi)
COUNTERWEIGHT DETAILS:
Moveable Counterweight:
T139185
1280 kg
SL counterweight
PLMXF2019
2155 kg
MAC 25 Axle Loads:
Axle loads for un-laden crane, boom fully retracted and boom angle at 0
o
.
No counterweight on crane:
Front Axle:
Rear Axle:
10330 kg
12290 kg
Counterweight on front:
Front Axle:
Rear Axle:
11900 kg
12000 kg
Counterweight on rear:
Front Axle:
Rear Axle:
10010 kg
13890 kg
Rear SL counterweight
Front Axle:
Rear Axle:
9465 kg
16590 kg
NOTE : The MAC 25 must not be driven on public roads and highways
with counterweight mounted on the rear of the crane.
T139154-D
10
