T169030A
6
3.2.2 Configuration 2 – 20-40°
Head Hook configuration 2 best for lifts between 20-40°
3.2.3 Configuration 3 – 40-55°
Head Hook configuration 3 best for lifts between 40-55°
T167845
T167844
T167844
T167845
