Terex PT60 - Operating Specifications; Fluid Specifications and Capacities; Dimensions and Weights

3 TECHNICAL DATA
37
3.6 Transmission PT-50 [PT-60]
3.7 Auxiliary Hydraulics PT-50 [PT-60]
3.8 Ground pressure PT-50 [PT-60]
3.9 Operating Specs. PT-50 [PT-60]
Note: The Maximum Gross Vehicle Weight of the PT-50/60 is not to exceed 8500
lb. (3856 kg). This excludes an operator, but does include accessories, attach-
ments and material being carried.
3.10 Capacities (approx) PT-50 [PT-60]
Make
Rexroth Rexroth
Type
A22VG A22VG
Design
Variable disp. / axial piston Variable disp. / axial piston
Discplacement
2.35 in. ³ (38.5 cc)/revolution 2.35 in. ³ (38.5 cc)/revolution
Relief Pressure
5500
p
si
(
37,920 kPa
)
5500
p
si
(
37,920 kPa
)
Make
Barnes-Haladex Barnes-Haladex
Type
180-2061 180-2061
Design
Gear Gear
Displacement
1.34 in. ³ (22 cc)/revolution 1.34 in. ³ (22 cc)/revolution
Relief pressure
3000 psi (20,684 kPa) 3000 psi (20,684 kPa)
Flow (2800 RPM)
17.4 gpm (65.9 lpm) 17.4 gpm (65.9 lpm)
At operating weight
3.6 psi (24.7 kPa) 3.6 psi (24.7 kPa)
At shipping weight
3.2 psi (21.8 kPa) 3.2 psi (21.8 kPa)
Tipping load
3800 lb (1724 kg) 3800 lb (1724 kg)
Operating capacity 50%
1900 lb (862 kg) 1900 lb (862 kg)
Operating capacity 35%
1330 lb (603 kg) 1330 lb (603 kg)
Fuel tank
13.7gal(51.9l) 13.7gal(51.9l)
Hydraulic tank
8gal(30.3l) 8gal(30.3l)
Engine coolant
2gal(7.5l) 2gal(7.5l)
En
g
ine oil includin
g
filter
2.8
g
al
(
10.6l
)
2.8
g
al
(
10.6l
)
