Terex TR40 - Page 8

SM 1664 1-99
2
* * * *
TABLE OF CONTENTS
Section No. Description SM No.
220 STEERING SYSTEM
0000 Steering System Schematic 1591
0040 Steering and Brake Control Tank 1592
0050 Steering Pump 1204
0080 Accumulator 1205
0090 Steering Valve 1206
0110 Double Relief Valve 1208
0120 Steering Cylinder and Linkage 1304
0130 Accumulator Valve 1209
0150 Steering Filter 1593
230 BODY SYSTEM
0000 Body System Schematic 1681
0040 Body and Disc Brake Cooling Tank 1595
0050 Tandem Pump 1213
0060 Body Control Valve 1685
0081 Body Control Joystick 1597
0090 Kick-over Valve 1218
0120 Relief Valve 1598
0121 Pilot Supply Valve 1599
0130 Body Cylinder 1221
250 BRAKING SYSTEM
0000 Braking System Schematic 1222
0050 Brake Manifold Valve 1223
0060 Accumulator 1600
0070 Treadle Valve 1225
0090 Directional Control Valve 1226
0100 Monoblock Brake Valve 1227
0130 Retarder Control Valve 1609
0140 Shuttle Valve 1229
260 OPERATORS COMPARTMENT
0010 Cab and Mounting 1602
0110 Passenger Seat and Mounting 1603
270 BODY
0010 Body and Mounting 1675
300 MISCELLANEOUS
0020 Lubrication System 1670
0070 Service Tools 1684
0080 Standard Bolt and Nut Torque Specifications 1238
0090 Unit Storage 1239
