Complete KTX unit contains Terma-SPLIT heang element and
controller for it. Depending on the model of the controller, it
can also be completed by a remote programmer.
1. Heang element
2. Capillary with temperature sensor
3. Heang element head
4. Controller
5. Blocking thread
6. Power wire (versions –PB, –PW, –SW)
7. Masking cover for X-type connecon (versions –MS)
1. Radiator powered by the heang element only, not connected to the central heang
system.
2. Water, water with an-freezing agent or the right type of oil should be used as
a heang agent – possibility of installaon and correct use is condioned by meeng
manufacturer’s requirements on the radiator and heang element.
3. Filling the radiator with too much liquid leads to exceeding of acceptable pressure
and damaging of the radiator or heang element. If you are lling the radiator
yourself, please act strictly according to the below instrucons.
4. Other methods of correct lling of radiator can be found on www.termaheat.pl.
Radiator should not be lled with a heang agent of temperature higher than 65°C.
5. Heang element should not be ed horizontally or turned downwards.
– Allen key 1.5 (included) – spanner no 24
The device must not be connected to electricity during installaon.
Unplug the device prior to installaon.
Please take every precauon when lling the radiator in order to
avoid being burnt by hot liquid!
1. Insert heang element (1) into the threaded opening at the boom end of the
collector.
2. Twist the head of the heang element with a spanner no 24.
3. Posion the element in such a way so that the indent in the head connecon (A) was
directed towards you or sideways.
4. Put the radiator in an oblique posion to make sure that the upper collector opening
is in the highest point.
The radiator must not be rested on the heang element controller or any other parts
of the connecon at any me!!!
5. Fill the radiator with the heang agent.
