18 19
OVERVIEW
Control panel
Left-right oscillation
Up/Down wind flow
Back section
Filter/Housing
Water container
Knob for
water container
Front housing
Water meter min-max
Handle
OPERATION
1. Your product can be controlled either by the manual controls on the top side of the
product or with the remote control.
2. The product can be used both as an Air Cooler and a Circulating Fan.
3. When using as a Circulating Fan, do not use the ‘Cool’ button as this,
in combination with water, is air cooling, so inly use the other functions.
4. When using as an Air Cooler, only fill with water as below and use the
‘COOL’ button. NOTE The Cool button may only be used when there is water in the tank.
5. The product also has a Sleep mode, in which the product pulsates air.
6. The air cooling function works well in rooms with a size of between 10-16 m²
7. The product creates more moist/cold air and makes the air quality feel fresher and
more healthy in the actual room in which it is being used. Keep in mind that the
product does not cool the air like an Air conditioner.
Water container with knob in
locked position.
Water container with knob in
Open position in order to pull
out the container.
Water container with 2
ice packs in transport position.
Take out both ice packs and
follow the instructions as below.
1. The ice packs contain an antibacterial agent (Standard Chlorine) to avoid any
bacteria/mould developing in the ice pack when it freezes - defrosts - freezes - defrosts.
a. Do not consume the contents of the ice pack.
b. It’s ok to pour the water from the ice pack into the regular drain.
2. Fill the ice packs with ordinary tap water just below the maximum mark on the ice packs
before cooling. NOTE! Too much water and the ice packs can crack when they freeze.
USAGE
HOW TO USE THE ICE PACKS
1. Put both ice packs in the freeze 3-5 hours before the first use
(The ice packs can be reused).
2. Tips on how to use the ice packs, 1 in the product and 1 in the freezer, then change
after one has defrosted.
3. Do not open the capsule in the ice pack.
4. Do not use the ice pack supplied for anything other than this product.
After it has been in the freezer, put 1 ice pack in the water container to keep
the water as cold as possible during usage and put the ice pack in as shown in the picture.
GB INSTRUCTION MANUAL GB INSTRUCTION MANUAL
