If a pellet stove in the “Hermetic” series is installed, it
ispossibletouseaspeciccoaxialpipethatallows
boththeexpulsionofuegasesandtheductingof
thecombustionairfromtheoutside(g.5.5A,B=Air
inlet C,D=Flue gas outlet).
5.5.1 Roof exhaust with traditional chimney
Theuefortheexpulsionofuegasesmustbe
developed in compliance with the UNI 10683- EN
1856-1-2- EN 1857- EN 1443- EN 13384-1-3- EN
12391-1 standards both regarding the dimensions
and the materials used in its construction.
DILAPIDATED chimneys, made with unsuitable
materials (brocement, galvanized steel, etc...
with rough and porous internal surfaces) are not
allowed and compromise the proper operation of
the stove.
Flue gases can be released through a traditional
chimney (Fig. 5.8) provided the proper
maintenance of the chimney is guaranteed;
For chimneys with a larger section, it is necessary
to “intubate” the chimney with steel piping (of
a diameter based on the path), which must be
properlyinsulated(g.5.9).
Check that the connection to the chimney in
masonry is properly sealed.
In case of pipes that pass through wooden roofs
orwalls,itisrecommendedtousespecialcertied
ducting kits commonly available on the market.
A) Windproof chimney stack
B) Seal
C) Inspection
1) Vermiculite and/or rock wool.
2) Steel piping.
3) Closing panel.
Fig. 5.8
Fig. 5.9
Fig. 5.5.2
1
2
3
