5. Child Seat Mounting
The HSD Rack is designed to mount a single approved child seat, such as the Thule Yepp Maxi or the Thule Yepp Nexxt Maxi.
As a general rule, place the child seat as forward as possible. Ensure the rider’s heel does not strike the child seat while pedaling.
The preferred placement for the Yepp Maxi child seat is Windows 1 on the Rack. If heel strike occurs, use Window 2. The
Nexxt Maxi child seat can be mounted along the length of Windows 1 and 2 in as forward position as possible.
Follow the installation instructions from the child seat manufacturer.
Do not accelerate hard, especially when going up steep hills to avoid front wheel lifting off ground
1 2
