Terrano terrano-x - Assembly on a Helmet; Helmet Type 1: Off-center vents; Helmet Type 2: Center vents

ENGLISH
| 5
ASSEMBLY ON A HELMET
Helmet Type 1:
O-center vents
Helmet Type 2:
Center vents
(go to page 5) (go to page 6)
Short Buckle Strap
Long Strap
Velcro Side
Smooth Side
Velcro Side
Smooth Side
Front
Front
Back
Back
➊ ➋
CradleSpoiler
Optional Spoiler
Deflect branches or other objects
Press here
Connect the Spoiler
Remove the Spoiler
CradleSpoiler
CLICK!
(go to page 6) (go to page 7)
