DMX 6Fire USB (English) 25
Headphone output (front)
The front of the unit features the headphone output (1/4" or 6.3 mm phone jack), above
which is a gain control that you can use to control the volume. This output always has the
same signal as output 1/2, which can be set to any signal.
Do yourself, and your hearing, a favour—before switching on the unit, check the position
of the gain control or turn it all the way down at first. Your ears will thank you! By the way,
it's no coincidence that we've put the headphone output right next to the microphone
input—this allows you to conveniently plug in your headset.
Drivers
The DMX 6Fire USB can log on to the system in either of two different ways. For more
information, read the description of "Device Settings" on Page 35
Multi-channel: here, all of the outputs are grouped in a multi-channel device. The
relevant driver is called "DMX 6Fire MC Out". The channels can be addressed individually
using common audio applications.
Multi-device: here, the outputs are registered on the system as separate devices, and
the drivers are then called "DMX 6Fire Waveplay 1/2, DMX 6Fire Waveplay 3/4, DMX
6Fire Waveplay 5/6 and DMX 6Fire Digital Play".
For more information on drivers, turn to page 27.
