TERSUS BCPI13 - Page 19

- 19 -
BCPI7 BCPI10
3*1.5 mm²
BCPI13 BCPI17
3*2.5 mm²
BCPI21 BCPI30
3*4 mm²
BCPI30(380V/3ph)
5*2.5 mm²
Terminal
Terminal cable max. 4 mm²
Figure 9
7.3 Circulation pump installation
The heat pump only provides a signal for the circulation pump, A separate A.C. Contactor is
required to connect the circulation pump.
