TES 46 - III. SPECIFICATIONS; Cable Length Measurement Specifications; Failure Detection Specifications; Coaxial, General, and Environmental Specs

OPENS
Range of open detection : 0 to 350m (0 to 999ft)
Accuracy of distance to an open :
UTP/FTP : 10% + 1m (10% + 3 ft)
SPLIT PAIRS
Range of detection : 2 to 350m (6 to 999ft)
Split pair part of the cable must be at least 2 meters (6ft) in length and
greater than 10% of the total cable length.
COAX Termination Measurements
Any loop resistance value between 5 and 350Ω is interpreted as a
termination resistance. Resistance value below 5Ω is considered
shorts and resistance value greater than 350Ω is not displayed.
General Specifications
Display : 2 lines of 16 characters LCD.
Power : Six AAA size 1.5V batteries.
Low Battery Indication : Display shown “LOW BATTERY”.
Battery Life : 100 hours.
Auto Power off : 5 minutes, (When there is no key activity).
Remote Cable Identifiers : #1 (#2 to #4 and #5 to #8 are optional).
Input Protection : 50V DC.
LAN Input Connectors : RJ45 and BNC.
Environinental Conditions :
Operating : 0 to +40℃ < 80%RH / Storage : -20 to +60℃ < 70%RH
Dimensions : Cable Tester 150 x 72 x 35mm
Remote identifier 60 x 23 x 22mm
Weight : Cable Tester 215g / Remote identifier 35g
4
IV. SETUP SELECTIONS
The setup mode allows to select and calibrate cable characteristics.
Once changed, these settings are stored and remain in the tester even
when tester is turned off.
Setup items :
r Select cable type (UTP, FTP, or COAX).
r Select a wiring standard.
r Select a cable category.
r Select a wire size.
r Calibrate cable length.
r Enable or disable the Beeper for ON and OFF.
Setup Procedure
1. Press SET key.
2. Press ¿ enter key to set up through the selections.
3. Press ▼ ▲ keys to select the desired setup condition.
4. Press ¿ enter key to move to the next setup selection, or press
SET key to exit the setup mode.
Power–up selection : Select length measurement units between feet
( ft ) and meters (m).
Power–up setup procedure
1. Turn off the tester, press and hold down SET key, then press and
hold down
power key, until display show LENGTH UNIT.
2. Press ▼or ▲ keys to the desired length units.
3. Press SET key to store the units and exit this mode.
5
