IV.MEASUREMENTS
4-1 DC Voltage Measurement
1). Connect red test lead to “ V-
Ω
-Hz “ terminal and black test lead
to “ COM “ terminal.
2). Set range switch to desired V
range and set DC / AC push
switch to DC position.
3). Connect Test prods of test leads IN PARALLEL to the circuit
being measured.
4). Read the voltage value displayed on LCD.
NOTE :
If the voltage is unknown before measurement, first , set
the function switch to the high-test range then, change to a
lower range, step by step.
When the “ OL “ is displayed, the measuring circuit is
overloaded. The function switch must be set to a higher
range.
Always avoid contact with high tension circuits when
measuring high voltage.
