V. BATTERY & FUSE REPLACEMENT
5-1 Battery Check-up & Replacement
WARNING
To prevent electrical hazard or shock turn off Multimeter and
disconnect test leads before removing back cover.
1). As battery power is not sufficient. will be displayed on LCD.
Replacement with a new 9V battery is required.
2). After test leads are disconnected and the Multimeter is furred off,
remove the bottom cover.
3). Remove battery from the holder and replace it with a standard 9 -
Volt transistor battery.
4). Replace the battery cover.
5-2 FUSE Replacement
WARNING
To prevent fire , use 0.5A / 250V size 5φ×20mm or 20A / 380V
size 6φ×30.8mm fast blow type fuse.
1). Turn off the Multimeter and disconnect test leads.
2). Remove back cover with a screw driver.
3). Referring to Figure 4, remove the defective fuse and install a new
fuse of the same size and rating.
4). Replace the battery cover.
