HIGH VOLTAGE BATTERY
Model 3 is equipped with a floor-mounted 400 volt lithium-ion high voltage battery. Never breach the high voltage battery when lifting
from under the vehicle. When using rescue tools, pay special attention to ensure that you do not breach the floor pan. Refer to Lifting
the Vehicle on page 24 for instructions on how to properly lift the vehicle.
NOTE: The following image shows a Dual Motor vehicle. Vehicles without a front drive unit are similar.
HIGH VOLTAGE BATTERY
Electric Vehicle Components 7
