Fuse Box 3
Fuse Rating Circuit Protected
71 40 A Condenser fan (left)
72 40 A Condenser fan (right)
73 40 A Vacuum pump
74 20 A 12V drive rail (cabin)
75 5 A Power steering
76 5 A ABS
77 25 A Stability control
78 20 A Headlights - high/low beam
79 30 A Light - exterior/interior
Maintenance
116 Model S Owner's Manual
