Fuse Box 4
If Model S is equipped with the cold weather option, an additional fuse box (4) is located under
the driver’s side trim panel. Access to fuse box 4 requires removal of several components that
must be performed by a Tesla service technician. The following fuse list is provided only to assist
you in determining if a fuse in this box needs to be replaced. Contact Tesla Service if one of these
fuses needs to be replaced.
Fuse Rating Circuit Protected
101 15 A Left rear seat heater
102 15 A Right rear seat heater
103 5 A Middle rear seat heater control
104 15 A Middle rear seat heater
105 15 A Wiper de-icer
106 - Not used
Maintenance
Maintenance 117
