7
ENG
Air inlet
Drainage pipe
Indoor Display
No. LED Function
1
Indicator for Timer, temperature and Error codes.
2
Lights up when Fresh Air function is on.
3
Lights up when Wi-Fi is on.
4
Lights up when Gentle Wind is on.
Note:
The air conditioner automatically adjusts the display brightness and buzzer sound according to the ambient light
intensity. When the air conditioner detects that the ambient light is weak for a period of time, it will automatically
turns off the display temporarily. If there is a remote control or APP operation, the display will display at a low
brightness for a short time, and the buzzer will respond at a lower volume; When the air conditioner detects that
the ambient light is strong for a period of time, exit the above operation.
The shape and position of switches and indicators may be different according to the model, but their function
is the same.
