TestEquity 1007H - Major Electrical Parts

Chapter 7 – Maintenance
TestEquity 1007H Temperature Chamber Page 7-17
Major Electrical Parts
Description
Mfr
Mfr Part No.
Ref #
Part #
Qty
UOM
Audible Alarm
Floyd Bell
MC-09-201-Q
AL1
200005
1
ea
Arc Suppressor
ITW Paktron
104MACQRL150
AS1-4, 6
200296
5
ea
Contactor, 3 P 30A
Hartland
HCC-3XT02SX
C1-3
200245
3
ea
Relay, DPDT, 30A
Magnecraft
92S11A22D-120
C4
200258
1
ea
Crankcase Heater, 45 W, 120 V
Copeland
018-0038-00
CC1
100030
1
ea
Relay, Octal DPDT 10A 120VAC
Idec
RR2P-UCAC120
CR1, 3, 4
200292
3
ea
Disconnect Switch, 3 Pole, 45A
ABB
OT63F3
DSW
200281
1
ea
Fuse, 4A
Bussman
FNQ-R-4
F1, 2
200183
2
ea
Fuse, 3A
Bussman
FNM-3
F11
200186
1
ea
Fuse, 15A
Bussman
FNQ-R-15
F3-4
200188
2
ea
Fuse, 15A
Bussman
LP-CC-15
F5-8
200187
4
ea
Fuse, 10A
Bussman
KTK-R-8
F9-10
200082
2
ea
Circulator Motor Kit
CUSTOM
CUSTOM
FM3
100575
1
ea
Heat Limiter Assembly
CUSTOM
CUSTOM
HL
222253
1
ea
Heater, Air
CUSTOM
CUSTOM
HT1
200181
1
ea
Heater, Humidifier
CUSTOM
CUSTOM
HT2
222385
1
ea
Light, 40W, 120V
Generic
Generic Appliance Light
LT1
Generic
1
ea
Indicator, Panel, 250V Neon
SoLiCo
S412-2-1-N2
PL1, 4
200026
2
ea
Indicator, Panel, 125V Neon
SoLiCo
S412-2-1-N1
PL2, 3
200025
2
ea
Pump Receptacle
Qualtek
738W-CX2/01
RCP1
222303
1
ea
Humidity Sensor
Vaisala
HMM100
RHS
200320
1
ea
Solid State Relay, 25A
Idec
RSSDN-25A
SSR1, 2
200021
2
ea
Solid State Relay, 5A
Omron
G3NA-205B-DC5-24
SSR3
200032
1
ea
Solid State Relay, 10A
Omron
G3NE-210T-US DC5
SSR4-6
200129
3
ea
Solenoid Valve Coil
Sporlan
MKC-1-120/50-60
SV1-4
100011
4
ea
Switch, SPST, Rocker
Carlingswitch
LRA211-RA-B/125N
SW1, 2
200023
2
ea
F4 Temp/Humidity Controller
Watlow
F4DH-CKCC-01AC
TCR1
200084
1
ea
F4T Temp/Humidity Controller
Watlow
F4T1L2EAA2F2018
TCR1
222511
1
ea
High/Low Limit Controller
Watlow
PM6L1AJ-AAAABAB
TCR2
200301
1
ea
Timing Module, On Delay
Airotronics
THCU30SC
TM1
200287
1
ea
Timing Module, Off Delay
Airotronics
TH3ML1300SC
TM2
280200
1
ea
Transformer, Control
Hammond
PH350MLI
TR1
200219
1
ea
Transformer, 20VAC
Hammond
166D20
TR2
200087
1
ea
Chart Recorder Option
Recorder, 2 Pen, 10"
Honeywell
DR4302-0000-G0100
RCD1
200098
1
ea
Paper, -90 to 210 C, 0 to 100
Graphic Controls
32002974 (Custom)
200155
1
ea
Pen, Purple, Six Pack
Honeywell
30735489-007
200097
1
ea
Pen, Red, Six Pack
Honeywell
30735489-002
200099
1
ea
