5 First steps
Pos: 27 /TD/Erst e Schritte/testo 550/ Erste Schritte testo 55 02 @ 17\mod_142313136780 9_79.docx @ 207272 @ 555 @ 1
Inserting batteries/rechargeable batteries
1. Fold out the suspension device and open the battery
compartment (clip lock).
2. Insert batteries (included in delivery) or rechargeable batteries
(4x 1.5 V, type AA/Mignon/LR6) in the battery compartment.
Observe the polarity!
3. Close the battery compartment.
- After inserting the batteries, the instrument switches on
automatically and goes into the settings menu.
When not in use for long period: Remove
batteries/rechargeable batteries.
Performing settings
1. Press [Set] repeatedly,
2. Press [▲] or [▼] to select the unit/parameter.
− The settings will be accepted once the last selection has been
made.
Key functions
Representation Explanation
[▲] or [▼]
Change parameter, select unit
[Set]
Select units/parameters
Adjustable parameters
Representation Explanation
°C, °F
Set temperature unit.
bar, kPa, MPa, psi
Set unit of pressure.
Pabs, Prel or psig Depending on the selected unit of pressure:
Switch between absolute and relative
pressure display.
14.7 psi
1.013 bar
Set current absolute pressure
/ /
Select measuring mode
AUTO OFF Automatic switch-off time, instrument
switches off after 30 minutes if no
temperature probe is connected and there is
no pressure apart from ambient pressure.
