6 Using the product
31
2. Move Joystick up/down to select the desired material.
- The selected material is highlighted orange ( ). The
corresponding emissivity is shown to the right next to the
material.
3. Move Joystick to the right to switch to the setting of the
emissivity (only available when selecting User defined) or to
Reflected temp..
- The selected option has an orange border ( ).
4. Confirm the selection with [OK].
- The selected number is highlighted orange ( ).
5. Move Joystick up/down to set the desired value. Move
Joystick right/left to change between the numbers.
6. Confirm the entry with [OK].
7. Confirm the settings with Apply.
- The changes are saved.
- The selected emissivity ( ) is shown at the bottom right in the
display in measurement view.
6.1.6. Palette
Change colour palette for the infrared image
You can choose between 10 existing palettes. The Ironbow HT
palette is intended specifically for measurements in the high-
temperature measuring range (low temperatures are shown with
higher contrast). The currently activated option is marked with a tick
( ).
1. [OK] | Palette| [OK].
2. Move Joystick up/down to select the desired option.
3. Confirm the selection with [OK].
6.1.7. Configuration
Time/date...
Time and date can be set. Time and date format are automatically
set based on the selected instrument language.
1. [OK] | Configuration… | [OK] | Time/date… | [OK].
- The Set time/date dialogue is opened.
2. Move Joystick up/down to select the desired option.
- The selected option has an orange border ( ).
3. Confirm the selection with [OK].
- The selected number is highlighted orange ( ).
