7
Description of instrument
5 function fields are set up around the data display which provide information on
additional functions during measurement. In order to set up these functions which can be
activated directly, leave the measurement window by pressing or . The current
measurement is then interrupted. The activated function field is shown in white with a
black background (inversed).
The
and
buttons switch between the options stored for this field. shows all
the options available in an additional window which can then be selected.
The target location for the measured data is shown at the top left, if transmission is
activated via the button. The data is then stored in the memory or printed.
The measuring location is shown at the top right facilitating the allocation of the data
to the measuring location during printing and analysis.
Below are the 3 currently available functions. The meaning changes depending on the
menu. The description in the display also changes accordingly. Not all of the function
buttons are allocated in every menu or with every probe.
If none of the function fields are inversed after pressing
or this means that current data measurement is activated.
The button takes you from the measured value display to the main menu. Otherwise
activates the selected function or confirms the contents of the selected window.
By pressing , selected processes or functions can be cancelled or you can leave
submenus. The always takes you back to the menu window until the main menu or
the activated data display appears.
i
Function buttons
