TEV Marstair CX 30 - NEW CX 17 SERIES MATCHED WITH NEW CKC 17 SERIES; LOW TEMPERATURE MATCH (Page 11); NEW CX;NEW CKC; NEW CX 17 SERIES MATCHED WITH OLD CKC 23 SERIES

11/19
55908014-17
NOTE: All refrigerant charges shown below are in grams
LOW TEMPERATURE MATCH
NEW CX 17 SERIES MATCHED WITH NEW CKC 17 SERIES
SYSTEM CX (NEW) CXE (NEW) CKC (NEW) 5 10 15 20
CX(E)30 + CKC20 55917001 55917017 55017720 679 794 909 1024
CX(E)40 + CKC30 55917002 55917016 55017730 884 1184 1484 1784
CX(E)50 + CKC50 55917003 55917015 55017722 1286 1586 1886 2186
CX(E)70 + CKC80 55917004 55917014 55017723 1410 1710 2010 2310
PART NUMBER
LIQUID LINE (m)
R407C
SYSTEM CX (NEW) CXE (NEW) CKC (NEW) 25 30 35 40 45 50 55 60 65 70 75 80
CX(E)30 + CKC20 55917001 55917017 55017720 964 1044 1124 1204 1284 1364 - - - - - -
CX(E)40 + CKC30 55917002 55917016 55017730 1324 1474 1624 1774 1924 2074 2224 2224 2524 2674 2824 2974
CX(E)50 + CKC50 55917003 55917015 55017722 1811 1961 2111 2261 2411 2561 2801 2801 3281 3521 3761 4001
CX(E)70 + CKC80 55917004 55917014 55017723 2655 2805 2955 3105 3255 3405 3645 3645 4125 4365 4605 4845
EXPANSION LINE (m)
R407C
PART NUMBER
SYSTEM CX (NEW) CXE (NEW) CKC (NEW) 5 10 15 20
CX(E)40 + CKC20 55917002 55917016 55017720 434 734 1034 1334
CX(E)50 + CKC40 55917003 55917015 55017741 546 846 1146 1446
CX(E)70 + CKC60 55917004 55917014 55017740 940 1240 1540 1840
LIQUID LINE
R407C
NEW CX/NEW CKC
PART NUMBER
SYSTEM CX (NEW) CXE (NEW) CKC (NEW) 25 30 35 40 45 50 55 60 65 70 75 80
CX(E)40 + CKC20 55917002 55917016 55017720 934 1084 1234 1384 1534 1684
CX(E)50 + CKC40 55917003 55917015 55017741 1186 1336 1486 1726 1966 2206 2356 2506 2656 2806 2956 3106
CX(E)70 + CKC60 55917004 55917014 55017740 1580 1730 1880 2030 2180 2330 2570 2810 3050 3290 3530 3770
EXPANSION LINE
R407C
NEW CX/NEW CKC
PART NUMBER
NEW CX 17 SERIES MATCHED WITH OLD CKC 23 SERIES
SYSTEM CX (NEW) CXE (NEW) CKC (OLD) 5 10 15 20
CX(E)30 + CKC20 55917001 55917017 55000720 918 1033 1148 1263
CX(E)40 + CKC30 55917002 55917016 55000730 1123 1423 1723 2023
CX(E)50 + CKC50 55917003 55917015 55000722 1809 2109 2409 2709
CX(E)70 + CKC80 55917004 55917014 55000723 1933 2233 2533 2833
PART NUMBER
LIQUID LINE (m)
R407C
SYSTEM CX (NEW) CXE (NEW) CKC (OLD) 25 30 35 40 45 50 55 60 65 70 75 80
CX(E)30 + CKC20 55917001 55917017 55000720 1203 1283 1363 1443 1523 1603
CX(E)40 + CKC30 55917002 55917016 55000730 1563 1713 1863 2013 2163 2313 2463 2463 2763 2913 3063 3213
CX(E)50 + CKC50 55917003 55917015 55000722 2334 2484 2634 2784 2934 3084 3324 3324 3804 4044 4284 4524
CX(E)70 + CKC80 55917004 55917014 55000723 3178 3328 3478 3628 3778 3928 4168 4168 4648 4888 5128 5368
EXPANSION LINE (m)
R407C
PART NUMBER
LOW TEMPERATURE MATCH
