TEV Marstair CX 30 - DIMENSIONS & WEIGHTS; PERFORMANCE DATA (kW)

4/19
55908014-17
MODEL
UNPACKED
PACKED
CX(E)
HEIGHT
WIDTH
DEPTH
WEIGHT
HEIGHT
WIDTH
DEPTH
WEIGHT
30
483
845
320
18
530
950
370
21
40
483
845
320
18
530
950
370
21
50
483
845
320
20
530
950
370
23
70
483
845
320
23
530
950
370
26
CKC
HEIGHT
WIDTH
DEPTH
WEIGHT
HEIGHT
WIDTH
DEPTH
WEIGHT
1Ph
3Ph
1Ph
3Ph
20
620
900
310
46
-
625
980
340
48
-
30
620
900
310
48
-
625
980
340
55
-
50
720
1000
310
64
-
730
1080
340
66
-
60
720
1000
310
64
730
1080
340
66
-
80
720
1000
310
66
64
730
1080
340
68
66
MODEL
RATING CONDITIONS
(ROOM 12.7C / 10C) (AMBIENT 27C / 19C)
OPTIONAL ELECTRIC
HEATER
TOTAL
SHR
SENSIBLE
240V
230V
CX(E) 30 + CKC 20
2.80
0.75
2.10
3.25
3.0
CX(E) 40 + CKC 30
3.30
0.68
2.24
3.25
3.0
CX(E) 50 + CKC 50
4.60
0.66
3.02
3.25
3.0
CX(E) 70 + CKC 80
6.80
0.63
4.30
3.25
3.0
MODEL
RATING CONDITIONS
(ROOM 12.7C / 10C) (AMBIENT 35C / 19C)
OPTIONAL ELECTRIC
HEATER
TOTAL
SHR
SENSIBLE
240V
230V
CX(E) 30 + CKC 20
2.38
0.75
1.79
3.25
3.0
CX(E) 40 + CKC 30
2.81
0.68
1.90
3.25
3.0
CX(E) 50 + CKC 50
3.91
0.66
2.57
3.25
3.0
CX(E) 70 + CKC 80
5.78
0.63
3.66
3.25
3.0
Low Temperature Match
MODEL
RATING CONDITIONS
(ROOM 5Cdb/ 3Cwb) (AMBIENT 27C / 19C)
OPTIONAL ELECTRIC
HEATER
TOTAL
SHR
SENSIBLE
240V
230V
CXE 40 + CKC 20
2.3
0.85
2.0
3.3
3.0
CXE 50 + CKC 40
3.5
0.80
2.8
3.3
3.0
CXE 70 + CKC 60
5.0
0.70
3.5
3.3
3.0
MODEL
RATING CONDITIONS
(ROOM 5Cdb/ 3Cwb) (AMBIENT 35C / 19C)
OPTIONAL ELECTRIC
HEATER
TOTAL
SHR
SENSIBLE
240V
230V
CXE 40 + CKC 20
2.0
0.85
1.7
3.3
3.0
CXE 50 + CKC 40
3.0
0.80
2.4
3.3
3.0
PERFORMANCE DATA (kW)
DIMENSIONS & WEIGHTS
