8
Helpline No. UK/Northern Ireland 01270 508538 Rep. Ireland 1800 995 036
Web Support www.quesh.co.uk
Model Number: 43744
Installation
Supplied Parts
Din Rear-Mount
Installation using the screw holes on both sides of the unit.
1. Screw holes on the side of
the unit.
2. Screws. Use either truss screws
(5x8mm) or flush surface screws
(4x8mm), depending on the
shape of the screw holes in the
bracket.
3. Vehicle factory mounting
bracket.
4. Dashboard or console.
5. Hook (remove this part)
Note: The mounting sleeve, outer
trim ring and the mounting strap
are not used for this method of
installation.
2 Keys
1 Hex Nut
2 Lock Washers
1 Sheet Metal Screw
1 Metal Support Strap
2 Flat Washers
1 Mounting Bolt
1 Faceplate Case (not
shown)
1 1/8” Stereo Cable
1 USB Extension Cable
1 Remote Control
