Installation
Helpline No. UK/Northern Ireland 01270 508538 Rep.Ireland 1800 995 036
Web Support www.quesh.co.uk
Model No: 47743
8
Din Rear-Mount
Installation using the screw holes on both sides of the unit.
1.Screw holes on the side of the unit.
2.Screws. Use either truss screws
(5x8mm) or flush surface screws
(4x8mm), depending on the shape
of the screw holes in the bracket.
3.Vehicle factory mounting bracket.
4.Dashboard or console.
5.Hook (remove this part).
Note: The mounting sleeve, outer trim
ring and the mounting strap are not
used for this method of installation.
Supplied Parts:
2 x Keys
1 x Remote Control
1 x USB Extension
Cable
1 x Aux Cable
1 x Faceplate Case
1 x Flat Washer
1 x Metal Screw
1 x Metal Support
Strap
