Installation
Helpline No. UK/Northern Ireland 01270 508538 Rep.Ireland 1800 995 036
Web Support www.quesh.co.uk
Model No: 47743
7
WARNING!
Disconnect negative battery terminal from battery before starting
installation. Consult the vehicle owners manual for proper
instructions.
Note 1:
Mark the polarity of the existing speaker wires before disconnecting
battery.
Note 2:
Remove the two transport screws from the top of the unit before installing.
Din Front Mount
1. After removing the old
radio and mounting sleeve,
insert supplied mounting
sleeve into opening
2. Bend the tabs on the
mounting sleeve to keep
the mounting sleeve firmly
in place.
3. Attach wires from the
unit to existing wires. See
wiring connections diagram.
Insert radio into dashboard.
Then apply the trim face to
the outside of the radio.
4. Support radio using
supplied rear mounting bolt
and steal bar. See parts list.
To Next Page
