J2 and J8
Power Jumpers
S1
MSP430 Serial
Disconnect
Switch
J6 and J7
Capacitive Touch
BoosterPack
Headers
J1
Power Input
J5
MSP430
Programming
Interface
J3,J9 and J4,J10 and J11
LaunchPadXL Socket
Hardware Resource Mapping
www.ti.com
Figure 9. LED BoosterPack Jumper, Connector, and Switch Locations
14
C2000 LED BoosterPack SPRUHH9–July 2012
Submit Documentation Feedback
Copyright © 2012, Texas Instruments Incorporated
