TPA3116D2
,
TPA3118D2
,
TPA3130D2
www.ti.com
SLOS708G APRIL 2012REVISED DECEMBER 2017
Product Folder Links: TPA3116D2 TPA3118D2 TPA3130D2
Submit Documentation FeedbackCopyright © 2012–2017, Texas Instruments Incorporated
(1) Stresses beyond those listed under absolute maximum ratings may cause permanent damage to the device. These are stress ratings
only, and functional operation of the device at these or any other conditions beyond those indicated under recommended operating
conditions is not implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
(2) 100 kΩ series resistor is needed if maximum slew rate is exceeded.
6 Specifications
6.1 Absolute Maximum Ratings
over operating free-air temperature range (unless otherwise noted)
(1)
MIN MAX UNIT
Supply voltage, V
CC
PV
CC
, AV
CC
–0.3 30 V
Input voltage, V
I
INPL, INNL, INPR, INNR –0.3 6.3 V
PLIMIT, GAIN / SLV, SYNC –0.3 GVDD+0.3 V
AM0, AM1, AM2, MUTE, SDZ, MODSEL –0.3 PVCC+0.3 V
Slew rate, maximum
(2)
AM0, AM1, AM2, MUTE, SDZ, MODSEL 10 V/ms
Operating free-air temperature, T
A
–40 85 °C
Operating junction temperature , T
J
–40 150 °C
Storage temperature, T
stg
–40 125 °C
(1) JEDEC document JEP155 states that 500-V HBM allows safe manufacturing with a standard ESD control process.
(2) JEDEC document JEP157 states that 250-V CDM allows safe manufacturing with a standard ESD control process. .
6.2 ESD Ratings
VALUE UNIT
V
(ESD)
Electrostatic discharge
Human-body model (HBM), per ANSI/ESDA/JEDEC JS-001
(1)
±2000
V
Charged-device model (CDM), per JEDEC specification JESD22-
C101
(2)
±500
6.3 Recommended Operating Conditions
over operating free-air temperature range (unless otherwise noted)
MIN NOM MAX UNIT
V
CC
Supply voltage PV
CC
, AV
CC
4.5 26 V
V
IH
High-level input
voltage
AM0, AM1, AM2, MUTE, SDZ, SYNC, MODSEL 2 V
V
IL
Low-level input
voltage
AM0, AM1, AM2, MUTE, SDZ, SYNC, MODSEL 0.8 V
V
OL
Low-level output
voltage
FAULTZ, R
PULL-UP
= 100 kΩ, PV
CC
= 26 V 0.8 V
I
IH
High-level input
current
AM0, AM1, AM2, MUTE, SDZ, MODSEL (V
I
= 2 V, V
CC
= 18 V) 50 µA
R
L
(BTL)
Minimum load
Impedance
Output filter: L = 10 µH, C = 680 nF
TPA3116D2, TPA3118D2 3.2 4
Ω
TPA3130D2 5.6 8
R
L
(PBTL) Output filter: L = 10 µH, C = 1 µF
TPA3116D2, TPA3118D2 1.6
TPA3130D2 3.2 4
L
o
Output-filter
Inductance
Minimum output filter inductance under short-circuit condition 1 µH
