USB2ANY Cable Connections
Table 3. 30-pin Cable Pinouts (continued)
Schematic Pin Number Cable Pin Number Signals Available
J3-5 4 GND
J3-4 5 PWM3
J3-3 6 GND
J3-2 7 DAC1
J3-1 8 GND
— 9 (unused)
— 10 (unused)
J4-10 11 GPIO7, PWM0, INT2, OW2, OW5
J4-9 12 GPIO6, PWM1, RFFE:SCLK, SPI:CS, INT1, µWIRE:CS, OW1
J4-8 13 GPIO5, SPI:SOMI, UART:RXD, µWIRE:SOMI
J4-7 14 GPIO4, SPI:SIMO, UART:TXD, µWIRE:SIMO
J4-6 15 3.3VEXT
J4-5 16 GND
J4-4 17 GPIO3, PWM2, RFFE:SDATA, INT0
J4-3 18 GPIO2, ES:DOUT, SPI:SCLK, µWIRE:SCLK
J4-2 19 GPIO1, I2C:SCL, OW3
J4-1 20 GPIO0, I2C:SDA, OW4
— 21 (unused)
— 22 (unused)
J5-8 23 ADC0
J5-7 24 ADC1
J5-6 25 GPIO9, ADC2, ES:AIN
J5-5 26 GPIO8, ADC3
J5-4 27 GND
J5-3 28 GND
J5-2 29 GPIO11, VREF+
J5-1 30 GPIO10, VREF–
NOTE: The pin numbers for J3, J4, and J5 on the schematics are for reference only and do not
correspond to the pin numbers for cable connections.
