Introduction
www.ti.com
2
SNAU228–January 2018
Submit Documentation Feedback
Copyright © 2018, Texas Instruments Incorporated
USB2ANY Interface Adapter
8 Connection Between the USB2ANY and the EVM...................................................................... 9
9 USB2ANY Schematic 1 ................................................................................................... 10
10 USB2ANY Schematic 2 ................................................................................................... 11
11 USB2ANY Schematic 3 ................................................................................................... 12
12 USB2ANY Interface Connectors ......................................................................................... 13
13 10-Pin IDC Cable Connector ............................................................................................. 14
14 10-Pin IDC Cable Detail................................................................................................... 14
15 30-Pin IDC Cable Connector ............................................................................................. 15
16 30-Pin IDC Cable Detail ................................................................................................... 15
List of Tables
1 Status LEDs .................................................................................................................. 6
2 10-pin Cable Pinouts....................................................................................................... 14
3 30-pin Cable Pinouts....................................................................................................... 15
Trademarks
All trademarks are the property of their respective owners.
1 Introduction
1.1 How to Use This Manual
This document contains the following chapters:
• Chapter 1 – Introduction
• Chapter 2 – Overview of Hardware Design
• Chapter 3 – Connecting the USB2ANY
• Appendices
1.2 Information About Cautions and Warnings
CAUTION
The EVM contains components that can potentially be damaged by electrostatic
discharge. Always transport and store the EVM in the supplied ESD bag, when
not in use. Handle using an antistatic wristband. Operate on an antistatic work
surface. For more information on proper handling, refer to Electrostatic
Discharge (ESD).
Due to the limited use and location of use (antistatic professional laboratory or other controlled
environment) the equipment under test (EUT) will not see an ESD event above 2 kV, and was tested
accordingly. Manufacturer’s specifications in the manual include this limitation.
