Texecom Capture D15-W - Quick Installation and Setup; Opening the Motion Detector

INS879EN-2 4/68
1.0 Quick installation
1.1 Opening the device
The devices are supplied in the unlocked position. If locked;
Use a flat bladed terminal driver and turn the locking mechanism ¼
turn anti-clockwise.
Slide the front down and towards you to remove.
For ceiling mount devices remove the facia by turning it anti-clockwise,
and then unlock as above.
Locking mechanism
Opening the device
