INS878EN-2 31/68
Resistance & voltage readings
Resistance and voltage readings should be recorded at the time of installation.
Voltage readings should be taken at the device
Resistance reading should be taken at the CIE or ACE where the circuit is
terminated.
2.0 Variants
2.1 CAPTURE P15
