INS879EN-9 71/73
Current During Supervision
(Period)
18mA (40ms) 18mA (40ms)
Supervision Frequency (Per
Hour)
4 4
PSU Characteristics (Type C)
Capacity of Supplied Battery 1250mAH
Low Voltage Signal 2.85V
End of Life Voltage 2.20V
After the low battery value has been signalled the product will operate for a
minimum of 30 days with an average daily current draw of 21uA (22uA for the
D20-W and CD-W). The battery will have a remaining capacity of at least 27mAhrs
after low battery is signalled.
When replacing the battery in the product, care should be taken to only use a
battery with a similar or greater capacity.
Note: A low battery signal can only be cleared by replacing the device's battery.
5.0 Legal information
5.1 Supplier
Texecom Ltd, Haslingden, Lancashire, BB4 4PW, UK.
Made in England
