Screws & Fixings
A minimum of 2 opposing fixing holes should be used to ensure maximum stability.
When corner mounting care should be taken to ensure the chassis is not twisted, if
the corner is uneven then two fixings on the same side would be acceptable.
Where removal from mounting detection is required you must ensure that the
tamper fixing is opposite to at least one of the corner or wall fixings.
Dependent on the mounting substrate, suitable fixings may be required. The size
and type will depend on the choice of fixing screw.
Minimum screw size 3.5 X 16mm CSK
Maximum screw size 4.0 X 70mm CSK
Cable Routing
If the bottom cable entries are used, care should be taken to ensure that the cable
To Next Page
