Texecom CAPTURE Q20 - 1.0 Quick installation; 1.1 Opening the device

INS878EN-2 4/68
1.0 Quick installation
1.1 Opening the device
The devices are supplied in the unlocked position. If locked.
Use a flat bladed terminal driver and turn the locking mechanism ¼ turn anti-
clockwise.
Slide the front down and towards you to remove.
For ceiling mount devices remove the facia by turning it anti-clockwise, and
then unlock as above.
Locking Mechanism
Opening the device
