Right
X 33 36
Y+ 6 7.5
Y- 6 8
Z+ 50 52
Z- 35 41
Left
X 24 30
Y+ 5 7
Y- 7 8.5
Z+ 52 56
Z- 27 33
Once the correct position has been located fix the magnet in place (see figure
6).
Figure 6

Texecom Impaq SC-W Specifications

General

Brand	Texecom
Model	Impaq SC-W
Category	Security Sensors
Language	English
