INS876-1 6/15
2.2 Additional inputs 1&2
The Impaq SC-W has 2 additional inputs. These may be used for any normally
closed output device and utilise wireless transmission to the receiver. Typical
examples for use are:
Any locally powered device with a normally closed output e.g. Smoke
detectors, Glass Break detectors, Movement Sensors, Flood detectors etc.
Any non-powered normally closed output device, e.g. Specialist magnetic
contacts, fixed PA buttons etc.
2.3 Learning the device to the system
To learn the device to the system:
Select an empty zone slot for the device and put the system into learn mode.
To power up press and hold the sensitivity button for 3 seconds.
The LED will flash pink while it communicates to the receiver. The LED will
turn green if the device has successfully learnt onto the system. If the LED
turns red the learn has failed.
Check the system is in learn mode.
Move closer to the panel or expander.
Ensure you are learning the device to an “empty” zone.
NOTE: The device will provide a low battery signal to the panel, once this signal is
displayed the battery should be replaced within 30 days.
Configure the DIP switches so that the sensor/s you want to use are set to the
ON position (see example in figure 3).
Figure 3
