Odyssey X Installation Manual
INS627-2 13
The unit incorporates software which disables the strobe whilst the tamper switch remains open. This is a safety feature and cannot be
disabled.
The piezo drive produces high voltages when the siren is sounding. While not directly hazardous, these voltages will cause discomfort
and should be avoided, particularly when using tools or a ladder.
The piezo transformer TF1 and surrounding components will be hot during and after sounding. While not directly hazardous, contact when
hot will cause discomfort and should be avoided, particularly when using tools or a ladder.
Failure to observe the following precautions regarding the batteries could lead to the danger of heating, ignition or explosion:
Always observe local regulations
Do not throw into a fire
Do not overcharge
Do Not Short Circuit
Replace only with the same type
Do not heat
Do Not Reverse Charge
Do not disassemble
Technical Specification
Environmental Electrical Wired Units
Volume (SAB mode at 13.7VDC) Supply Voltage 12-16 VDC (13.7 nominal)
X-W
X-E & X-EB
105dB Peak at 1m (A Weighting, 90°)
109dB Peak at 1m (A Weighting, 90°)
Current Drain (typical at 13.7VDC)
X & X-B Models:
115dB Peak at 1m (A Weighting, 90°)
Quiescent: 18mA With backlight 58mA
Acoustic Output Varying Sound Output
Strobe: 100mA
Cut-Off Time:
15 minutes
Sounder SAB LC SCB
Waterproof Coating: Conformal
X-E Models: 285mA 160mA 30mA
X-BE 325mA 200mA 70mA
X Models: 405mA 190mA 30mA
Environmental Protection
X-B Models 445mA 230mA 70mA
X-E & X-BE Models:
Weather Resistant
Standby Battery
X-W, X & X-B Models:
Type: NiMh Stack
Operating Temperature:
-25°C (-13°F) to +55°C (+131°F)
Voltage: 7.2VDC (nominal)
Storage Temperature:
-25°C (-13°F) to +60°C (+140°F)
Capacity: 250mAh
EMC Environment:
Residential / Commercial /Light Industrial
/ Industrial
Flash Tube:
1Ws Xenon
Physical
Flash Rate:
1Hz (typical)*
Material
Discharge Time (
60VDC): 180 seconds
Backplate All Models 3mm Polycarbonate Comfort LEDs
Covers All Models 3mm Polycarbonate/3mm PMMA High Intensity White
Tamper Detection
Brightness: 100mcd (typical)
All models Wall & Inner cover
Flash Rate (tamper
secure):
1Hz alternating
(typical)
Lid Dimensions (h x w x d)
Electrical Wireless
X3
290mm x 276mm x 58mm
Supply Voltage:
12V DC
X1
290mm x 186mm x 58mm
Battery Type:
8 x Lithium type
AA 1.5V
Module Dimensions (h x w x
d)
287mm x 170mm x 51
High Power LED Strobe:
320lm
Flash Rate:
1Hz (typical)*
Packed Weight
Module only (Not X-W) 791g (28oz) approx>
Comfort LEDs:
Module only Odyssey X-W 991g (35oz) approx>
X1 Cover 310g (11oz) approx.
Brightness: 100mcd (typical)
X3 Cover 613g (22oz) approx.
Flash Rate (tamper secure): 1/4 sec flash at 5
sec intervals
alternating
(typical)
Wireless Frequency: 868.0MHz
868.6MHz
* Wired Units The flash rate will reduce to 0.125Hz after flashing for one hour (1 flash every 8 seconds). This is a software feature to reduce power consumption
and cannot be disabled.
*Wireless Units The flash rate will reduce to 0.125Hz after flashing for 20 minutes (1 flash every 8 seconds). This is a software feature to reduce power
consumption and cannot be disabled. After 10 days the strobe is cancelled completely. Turning the strobe off then on again will resume normal operation. In
extreme conditions where the temperature is likely to exceed the stated maximum avoid direct sunlight.
Total alarm current = Quiescent + Strobe + Sounder current.
