Odyssey X Installation Manual
INS627-2 3
Accessing the Unit
Odyssey X1 Shown, all models are the same.
Undo the screw ( no need to remove it completely) and
depress the tab to open the lid
The Lid has two parked positions
Undo the screw and press the tab to access Wiring & Tamper Inner cover open
Removing the lid completely
To completely remove the lid pull the lid to the left or right at the hinge points shown and then lift off.
Ta b
