8. Specifications
INS352-5 10
9. Physical Specifications
Mounting Height:
1.0 - 1.4m, 1.2m nominal
Supply Voltage:
9-16 V
DC
Current Drain (typical):
28mA
Detection Method:
Dual, non-overlapping, digital PIR
Range:
12m max. Adjustable to 8m, 5m and 2m
Alarm Output:
NC/NO selectable relay. Rated 50V
DC, 100mA, 18Ω
Tamper Detection:
Wall and case. Sealed non-mechanical switch.
Tamper Output:
NC relay. Rated 50V
DC, 100mA, 18Ω
LED Indication:
Red alarm indication
Environmental Protection:
IP65
Waterproof Coating:
Conformal
EMC:
EN 50130-4: 1996, A1 1998, A2 2002. EN 55022: Class B
89mm 86.5mm
250mm
550g (20oz)
approx.
-35°C (-31°F) to
+60°C (+140°F)
-35°C (-31°F) to
+55°C (+131°F)
