Fig. 9 Cable Joint for Under Water Application

Procedure for joining and insulating the

3 core conductors

Proedure for joining and insulating the

cable joint for under-water cable

Step 1: Soldering / knot the copper strands Step 6: Layer 1 - 1st layer of virgin rubber insulation

Step 7: Layer 2 - 1st layer of PVC insulation tape

Step 8: Layer 3 - 2nd layer of PVC insulation tape

Step 2: Layer 1 - 1st layer of virgin rubber insulation

Step 3: Layer 2 - 1st layer of PVC insulation tape

Step 4: Layer 3 - 2nd layer of virgin rubber insulation

Step 5: Layer 4 - 2nd layer of PVC insulation tape

OMOW002A 19 2020.01
