Page K-3
THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
REAR AXLE
660325 Service Parts Manual
31 620363 DIFFERENTIAL COVER ASSEMBLY KIT
(INCLUDES ITEMS 32, 33) ................................................................ 1
32 620347 RUBBER PLUG ........................................................................... 1
33 620348 DIFERENTIAL COVER PLATE.................................................... 1
34
35
36 608811 END CAP PLUG ................................................................................ 2
37 614208 AXLE SHAFT, LONG (DRIVER SIDE) ............................................... 1
38 614209 AXLE SHAFT, SHORT (PASSENGER SIDE)..................................... 1
39 620342 RETAINING RING .............................................................................. 4
40 620343 BALL BEARING.................................................................................. 2
41 620344 OIL SEAL............................................................................................ 2
42 620345 O-RING............................................................................................... 2
43
44 614756 LIMITED SLIP DIFFERENTIAL KIT.................................................... 1
45 601084 LOCK NUT, 3/8” - 24 .......................................................................... 4
46 620335 FLANGED HEX HEAD BOLT, 3/8” - 24 X 1.25" LG............................ 4
47 620346 FLANGED HEX HEAD BOLT, 5/16” - 18 X .75" LG............................ 10
48
49 620357 AXLE VENT........................................................................................ 1
50 620358 O-RING............................................................................................... 2
51 620359 RETAINING RING .............................................................................. 2
52
53 72763G02 SCUFF GUARD............................................................................................... 1
