Page M-3
THE USE OF NON U.L. PARTS WILL VOID ANY U.L. LISTING.
When ordering parts, please specify the model and serial number of the product.
* Indicates a component that is not available as an individual part.V
*** Indicates consult Customer Service Department for additional information.
ITEM PART NO. 12345 DESCRIPTION QTY.
SEATING
660325 Service Parts Manual
22 603800 FLANGED HEX HEAD BOLT, M10 - 1.5 X 50MM LG ..................................... 2
23 600525 FLANGED LOCK NUT, M10 - 1.5.................................................................... 2
24
25 600527 BUTTON HEAD TORX BOLT, M10 - 1.5 X 60 MM LG.................................... 4
26 600525 LOCK NUT, M10 - 1.5...................................................................................... 4
27
28 645088 SEAT BACK SUPPORT STRUT COVER........................................................ 2
29
30 602742 SWEATER BASKET ASSEMBLY (INCLUDES ITEMS 31 - 34) ...................... 1
31 * SWEATER BASKET ................................................................................. 1
32 608051 CLAMP (BAGRACK)................................................................................. 2
33 16816G1 RACHET RIVET, .25" X .680" .................................................................. 2
34 71853G01 BAG STRAP.............................................................................................. 1
35
36 600530 BUTTON HEAD TORX BOLT, M10 - 1.5 X 25 MM LG.................................... 2
37 *** PREMIUM SEAT BACK ASSEMBLY.............................................................. 1
647282G17 LIGHT BEIGE
38 *** PREMIUM SEAT BACK ASSEMBLY............................................................... 1
686149G18 MUSHROOM
686149G19 GRAY
686149G20 CUSTOM
39 *** PREMIUM SEAT BOTTOM ASSEMBLY (INCLUDES ITEMS 7 - 12, 40)........ 1
629269G1618 MUSHROOM
629269G1619 GRAY
629269G1620 CUSTOM
40 *** PREMIUM SEAT BOTTOM ASSEMBLY (INCLUDES ITEMS 41 - 43) ...... 1
686148G18 MUSHROOM
686148G19 GRAY
686148G20 CUSTOM
41 605502 WOODEN BASE ASSEMBLY ............................................................. 1
42 602551 COVER PLATE ................................................................................... 1
43 16816G2 RATCHET RIVET, .25" X .887"............................................................ 4
44 *** PREMIUM SEAT BOTTOM ASSEMBLY (INCLUDES ITEMS 7 - 12, 45) ....... 1
629269G1617 LIGHT BEIGE
45 *** PREMIUM SEAT BOTTOM ..................................................................... 1
647267G17 LIGHT BEIGE
To Next Page
