Textron Greenlee EK50ML User Manual

EK50ML Battery-powered Crimping Tool
Greenlee / A Textron Company
2
Description
The EK50ML Battery-powered Crimping Tool is a
hand-held, self-contained crimping tool intended to
crimp cable using Greenlee’s Kwik Cycle
®
9 and
CrimpALL
®
die sets as well as some competitors’
diesets.
U.S. patent pending.
Safety
Safety is essential in the use and maintenance of
Greenlee tools and equipment. This manual and any
markings on the tool provide information for avoiding
hazards and unsafe practices related to the use of this
tool. Observe all of the safety information provided.
Purpose of this Manual
This manual is intended to familiarize all personnel with
the safe operation and maintenance procedures for the
following Greenlee tool:
EK50ML Battery-powered Crimping Tool
Keep this manual available to all personnel.
Do not discard this product or throw away!
KEEP THIS MANUAL
Table of Contents
Description ..................................................................... 2
Safety ............................................................................. 2
Purpose of this Manual .................................................. 2
Important Safety Information ..................................... 3–4
Identication ................................................................... 5
Specications ................................................................. 5
Battery Charger .............................................................. 6
Operation .................................................................... 7–8
Maintenance ................................................................... 9
Troubleshooting ............................................................ 10
Die Holders ................................................................... 11
CrimpALL
®
Interchangeable Die Sets .....................11-13
Illustration ..................................................................... 14
Parts List .................................................................15-16
All specications are nominal and may change as design
improvements occur. Greenlee Textron Inc. shall not be liable for
damages resulting from misapplication or misuse of its products.
CrimpALL and Kwik Cycle are registered trademarks of
TextronInnovations Inc.
Teon is a registered trademark of Dupont.
